PRODUCT SPECIFICATIONS DETAILS

Vertical Concealed and Horizontal Visible Curtain Wall

Product Details:


Interior Viewing Size: 60, 65, 70, 75, 80, 90, 100...


Main Frame Series Dimensions: 80, 90, 100, 120, 150, 180, 200, 240...


Main Frame Connection Options: Angle Corner Connection, Core Insert Connection, Pin Connection, Horizontal and Vertical Frame Overlay Connection, etc.


Thermal Insulation Bridging Options: Strip-type Thermal Insulation Bridging Structure, Snap-on Thermal Insulation Bridging Structure


Compatible Glass Thickness: Suitable for various glass thicknesses, including single-layer, laminated, and multi-layer insulated glass.


Facade Appearance Styles: Full Visible Frame, Fully Concealed Frame, Vertical Visible and Horizontal Concealed, Vertical Concealed and Horizontal Visible


Curtain Wall Window Forms: Outward Opening Upper Hinged, Outward Opening Horizontal Sliding, Inward Tilt, Inward Horizontal Opening and Tilt, Visible Frame Opening, Concealed Frame Opening, Semi-Concealed Frame Opening, etc. Additionally, intelligent hardware can be optionally added to achieve versatile opening functionalities.


Complementary Product Design: Various structural sizes of operable frames, glass frames, curtain wall exterior covers, decorative louvers, decorative grilles, and other supporting designs. This offers customers a wide range of choices, accommodating diverse personalized design requirements.


Product Description


Aluminum alloy glass curtain wall bestows your building with an elegant and advanced appearance, along with exceptional performance. This curtain wall is a masterpiece that blends high-quality aluminum alloy with exquisite craftsmanship, offering outstanding thermal insulation, visual aesthetics, and sustainability to your architecture.


With its highly modern design, the aluminum alloy glass curtain wall invites natural light indoors, creating an open and bright space. Whether for office buildings, commercial centers, or hotels, it lends a captivating look to your structure, harmoniously integrating with the surrounding environment.


Advanced thermal insulation technology ensures stable indoor temperatures, establishing a comfortable and energy-efficient interior environment. Thoughtfully designed structures and sealing systems effectively isolate external noise and regulate temperature, providing you with a serene workspace and living area.


Beyond being an architectural focal point, the aluminum alloy glass curtain wall embodies energy efficiency and environmental consciousness. Its sustainable material selection and advanced insulation technology contribute to reduced energy consumption and a smaller carbon footprint.


By choosing the aluminum alloy glass curtain wall, you step into the forefront of modern architecture. It not only offers visual delight but also signifies a commitment to architectural performance and sustainable development. Together, let's create a brighter and more advanced future for architecture.

DRAWINGS

APPLICATION CASE
